JAN45160Z-003
450nm Blue Laser Targeted Pigment Optimization: Stubborn tattoo pigments (blue, green, purple inks) – which traditional red or infrared lasers struggle to break down – highly absorb the 450nm wavelength. The laser penetrates 0.5-3mm into the dermis layer, focusing exclusively on pigment particles without damaging the epidermis. It ensures thorough tattoo removal while minimizing pigment residue and skin irritation.
1.6W High Power for Efficient Medical Aesthetic Treatment: With stable power output, the 1.6W high power delivers concentrated energy to shatter large tattoo pigment clusters into micro-particles. The body’s lymphatic system then metabolizes these micro-particles, significantly shortening treatment cycles—4-6 sessions for medium-sized tattoos and 6-10 sessions for large professional tattoos. It outperforms low-power modules in medical aesthetic treatment efficiency.
Precision Spot & Focused Tattoo Removal Treatment: Equipped with medical-grade optical lenses, it offers an adjustable spot size (0.2-0.8mm) to match tattoo area, ink depth, and treatment needs. The narrow, focused laser beam ensures targeted tattoo removal, avoids damage to surrounding healthy skin, and minimizes post-treatment redness, swelling, or inflammation—critical for fine-line tattoos, small local tattoos, or delicate semi-permanent makeup removal.
Core Specification :
| Wavelength | 450nm |
| Output Power | 1.6W |
| Working Voltage | 5V |
| Beam Mode | Dot beam |
| Beam Size | ≤1mm @46.5mm |
| Housing Size | 13.5*26mm (Customizable) |
| Lifespan | 10,000 hours |


| Item | Parameter | ||||
| Wavelength | 375-405nm | 425-488nm | 515-520nm | 635-670nm | 780-980nm |
| Single Diode Module Optical Power | 20mw-3W | 20mw-3W | 10mw-1.6W | 5mw-2.5W | 5mw-75W |
| Multi Diodes Module Optical Power | 3W-200W | 6W-500W | 1.6W-50W | 2.5W-30W | 75W-100W |
| Operating Voltage | 3-5V/6V/ 12V/ 24V/ 30V/ 110V/ 220V/ 240V etc. | ||||
| Beam Mode | Dot/ Line/ Cross/ Grid/ Muti-lines/ DOE etc. | ||||
| Fan Angle Options of the Line Beam | 5°/10°/15°/20°/25°/30°/45°/60°/90°/110°/130°/180° etc. | ||||
| Optical Lens | Acrylic lenses, glass lenses, wave lenses, Powell lenses etc. | ||||
| Dimension | 4*8mm/ 6*10.5mm/12*15mm/9*21mm/16*66mm/ 33*33*55mm etc. | ||||
| CDRH Class | class1/class2/class3R/class3B/class4 | ||||
The Below are other laser pattern options you can select:

450nm Blue Laser Targeted Pigment Optimization: Stubborn tattoo pigments (blue, green, purple inks) – which traditional red or infrared lasers struggle to break down – highly absorb the 450nm wavelength. The laser penetrates 0.5-3mm into the dermis layer, focusing exclusively on pigment particles without damaging the epidermis. It ensures thorough tattoo removal while minimizing pigment residue and skin irritation.
1.6W High Power for Efficient Medical Aesthetic Treatment: With stable power output, the 1.6W high power delivers concentrated energy to shatter large tattoo pigment clusters into micro-particles. The body’s lymphatic system then metabolizes these micro-particles, significantly shortening treatment cycles—4-6 sessions for medium-sized tattoos and 6-10 sessions for large professional tattoos. It outperforms low-power modules in medical aesthetic treatment efficiency.
Precision Spot & Focused Tattoo Removal Treatment: Equipped with medical-grade optical lenses, it offers an adjustable spot size (0.2-0.8mm) to match tattoo area, ink depth, and treatment needs. The narrow, focused laser beam ensures targeted tattoo removal, avoids damage to surrounding healthy skin, and minimizes post-treatment redness, swelling, or inflammation—critical for fine-line tattoos, small local tattoos, or delicate semi-permanent makeup removal.
Core Specification :
| Wavelength | 450nm |
| Output Power | 1.6W |
| Working Voltage | 5V |
| Beam Mode | Dot beam |
| Beam Size | ≤1mm @46.5mm |
| Housing Size | 13.5*26mm (Customizable) |
| Lifespan | 10,000 hours |


| Item | Parameter | ||||
| Wavelength | 375-405nm | 425-488nm | 515-520nm | 635-670nm | 780-980nm |
| Single Diode Module Optical Power | 20mw-3W | 20mw-3W | 10mw-1.6W | 5mw-2.5W | 5mw-75W |
| Multi Diodes Module Optical Power | 3W-200W | 6W-500W | 1.6W-50W | 2.5W-30W | 75W-100W |
| Operating Voltage | 3-5V/6V/ 12V/ 24V/ 30V/ 110V/ 220V/ 240V etc. | ||||
| Beam Mode | Dot/ Line/ Cross/ Grid/ Muti-lines/ DOE etc. | ||||
| Fan Angle Options of the Line Beam | 5°/10°/15°/20°/25°/30°/45°/60°/90°/110°/130°/180° etc. | ||||
| Optical Lens | Acrylic lenses, glass lenses, wave lenses, Powell lenses etc. | ||||
| Dimension | 4*8mm/ 6*10.5mm/12*15mm/9*21mm/16*66mm/ 33*33*55mm etc. | ||||
| CDRH Class | class1/class2/class3R/class3B/class4 | ||||
The Below are other laser pattern options you can select:
