Single Mode 405nm 150mW Violet Fiber Coupled Laser Module for CTP Machine

The Single Mode 405nm 150mW Violet Fiber Coupled Laser Module is an industrial-grade high-precision optical device, featuring single-mode fiber transmission (ensuring excellent beam collimation and high spatial coherence), 405nm violet laser output (with strong photosensitive material excitation capability), and stable 150mW power (power fluctuation ≤±3% for consistent performance).

This Single Mode 405nm 150mW Violet Fiber Coupled Laser Module delivers high beam quality (low divergence ≤1mrad, uniform energy distribution) via its single-mode fiber, making it ideal for diverse professional scenarios: in LDI exposure, it provides precise light sources for fine circuit pattern imaging, supporting ultra-fine linewidths down to micrometer levels for high-density PCB manufacturing; in screen printing, its 405nm violet laser ensures accurate pattern projection, compatible with photosensitive emulsions to achieve sharp, high-resolution printing edges; for CTP/CTS systems, the module’s stable 150mW power and single-mode fiber transmission enable fast, clear plate-making, reducing exposure time while improving pattern accuracy and repeatability; in medical fields, it serves as a reliable light source for specific applications such as fluorescence excitation in diagnostic imaging or low-power phototherapy. Equipped with advanced thermal management to prevent overheating during long-term operation, efficient fiber coupling (coupling efficiency ≥90%), and broad compatibility with industrial control systems, the Single Mode 405nm 150mW Violet Fiber Coupled Laser Module balances precision and efficiency for demanding industrial and medical optical demands.
