The 375nm fiber coupled violet laser module is a high-performance near-UV laser source engineered for LDI laser direct imaging, maskless lithography, UV curing of polyurethane & acrylic resin, and micro-structuring processing. Adopting precision fiber coupling technology, laser outputs via flexible fiber pigtail, enabling flexible optical layout and seamless integration into various precision automatic equipment.
The 375nm wavelength perfectly matches the absorption peak of photoresist, solder mask ink and photoinitiators in UV polyurethane systems. It delivers higher light absorption efficiency than 405nm lasers, generates sharp pattern edges and achieves sub-micron patterning, significantly improving production yield for PCB, microfluidic chips and semiconductor substrates. Equipped with built-in TEC temperature control and constant-current driver, the module features outstanding power stability and low optical noise, supporting high-speed TTL modulation. Multiple fiber core sizes (105μm/200μm/400μm) and SMA905/FC connectors are optional with high coupling efficiency. With compact modular construction, air-cooled or water-cooled thermal solutions are available for long-hour continuous stable operation. It is ideal not only for industrial mass lithography exposure, but also for selective spot curing of polyurethane and UV adhesives without massive thermal damage.
It covers industrial precision manufacturing and scientific research. For industrial use: LDI lithography, PCB imaging, selective UV curing of polyurethane and micro-structuring. For laboratory research: fluorescence excitation, bio-detection and material spectral analysis, delivering reliable fiber-coupled UV laser solutions for advanced precision manufacturing.
Item | Spec |
|---|---|
Wavelength | 378nm ±5nm |
Output Power | mW level ~ 50W optional |
Fiber Type | Multimode fiber, core size 105/200/400μm optional |
Connector | SMA905 / FC-PC |
Modulation | High-speed TTL /PWM modulation |
Cooling | Air cooling / Water cooling optional |
Typical Applications | LDI lithography, PCB imaging, polyurethane UV curing, fluorescence detection, micro-processing |
BU-Laser specializes in R&D and customized manufacturing of laser sources, and can stably supply 375nm fiber coupled violet laser modules. Customization on output power, fiber parameters and connector types is available. We can support prototype testing and optical scheme evaluation for customers, providing one-stop laser source solutions for lithography, UV polyurethane curing and other applications. Samples are available upon request.
